● Less fuel consumption. Longer run-time
● Simple control system
● High efficiency
● Sturdy and durable
● Max height 7.2m
● Complete design and quality inspection
● 30 mins full load test
● Function testing
● Protection testing
● Ambient temperature: ＋5℃~40℃
● Altitude: ≤1000m
Note: Please contact us if operating environmental conditions required do not go with the guidance.
|
Lighting Tower Technical Data |
|
|
Power Package Rated Power |
6KW |
|
Number & Power of Lamp |
4×1000W |
|
Rated Frequency/ Speed |
50Hz /1500 rpm |
|
Rated Voltage |
AC 230V |
|
Noise |
65dB(A) @7M |
|
Mast-Maximum Height |
7.2M |
|
Mast Lifting & Extension |
Manual Operation |
|
Fuel level gauge |
Electronic |
|
Tower leg type |
Manual |
|
Trailer Load bearing |
900KG |
|
Trailer type |
Off road type |
|
AUX. Power output |
16A/3P Socket |
|
Rotation angle range of light |
355° |
|
Wind resistance grade |
65km/h |
|
Recommended use environment |
Level ground |
|
Lamp |
|
|
Number×Power |
4×1000W |
|
Lamp type |
Metal halide lamp |
|
Protection Glass |
IP44 |
|
Luminous Efficiency |
75Lm/W |
|
Color Temperature |
4200 K |
|
Voltage |
AC 240V |
|
Lamp sevice life |
10000hrs |
|
Control System |
|
|
Controller |
Model MALC404 |
|
Dimension and Weight
|
|
|
Max Overall Dimension (L×W×H) |
3060×2310×7200 mm |
|
Container loading Dimension (L×W×H) |
1550×1100×2450 mm |
|
Tank Capacity / Running Hr. |
100 L / 75 hrs. |
|
Weight |
810 kg |
|
The loading capacity(40'HC) |
15 Sets |
|
Engine Specifications |
|
|
Engine Model |
3D11G3/A |
|
Manufacturer |
Raywin |
|
Emission |
EU Stage V |
|
Number of Cylinders |
3 |
|
Cycle |
4 Stroke |
|
Aspiration |
Naturally |
|
Prime Power / Speed (Gross) |
9.1KW / 1500RPM |
|
Lube-oil Capability |
4.6L |
|
Fuel consumption |
≤290 g/kWh |
|
Starter motor/ Alternator |
12V 1.2kW |
|
Alternator Specifications |
|
|
Alternator Model |
DP06-50 |
|
Manufacturer |
Dingol |
|
Rated Output Power |
6KW |
|
Alternator Type |
Brushless |
|
Rated Voltage |
AC 230V |
|
Rated Speed |
1500 RPM |
|
IP Protection |
IP23 |
|
Insulation Grade |
H |
|
OPTIONS |
|
|
□ Jacket water heater |
□ Manual pump |
|
□ Lub-oil heater |
□ Smartgen controller |
|
□ ABB/Schneider MCB |
□ Sockets |
|
□ Battery charger |
□ Larger fuel tank |
● Anti-vibration mount
● Replaceable fuel filter, oil filter & air filter
● Cooling radiator and fan
● Starter battery (with lead acid) including rack and cables
● Flexible fuel connection hoses
● Exhaust silencer and bellows
● Operation manuals and circuit diagram document
Details
-
User-friendly operating interface and fully functional control system.
-
Branded engine.
-
LED lights.
-
Metal halide lights.
-
Big door for easy maintenance.
-
On/off road trailer.
-
Strong support legs.
-
Built-in large fuel tank.
